StarTech.com 4K7014IC-EXTEND-HDMI AV forlænger AV sender & modtager Sort

SKU: 1003662365
EAN: 0065030916165

StarTech.com 4K7014IC-EXTEND-HDMI, 3840 x 2160 pixel, AV sender & modtager, 70 m, Ledningsført, Sort
Mere info
6.289,00 DKK Ex. moms: 5.031,20 DKK På lager

Produktbeskrivelse

Split and extend a single 4K 60Hz HDMI signal to four HDMI displays over a distance of up to 230ft (70m) with Power over Cable

This HDMI extender and splitter delivers reliable 4K AV distribution to four displays over Ethernet cabling for professional AV installations. Enables flexible deployment using Ethernet cables for longer-range and in-wall runs. Ideal for centralized AV distribution in boardrooms, digital signage, educational facilities, and hospitality environments.

HDMI Over Ethernet Cabling

Extend HDMI signals to four remote displays over CAT6/6a cabling using a single transmitter. Transmitter features a HDMI output providing a direct connection for a local display. Supports 4K 60Hz video and 2 channel audio up to 230ft (70m). Includes IR extension support for remote control of the source device from any connected display.

Powered with a Single Power Adapter

Single power adapter connects to the transmitter; all four receivers are powered directly over the CAT6/6a cables. Simplifies installation in environments with limited power access and reduces overall cable clutter.

No Drivers, Software, or IP Configuration

Plug-and-play installation with no additional drivers, software, or network setup required. Supports any operating system including Windows, macOS, and ChromeOS, and is compatible with all hardware platforms including Intel, AMD, and Apple Silicon.

Versatile Mounting Options

1x4 HDMI distribution kit includes mounting brackets for wall, ceiling, or under-table installation at both transmitter and receiver locations. Compact form factor enables discreet installation in tight spaces.

Specifikationer

Type AV sender & modtager
Maksimal opløsning 3840 x 2160 pixel
Understøttede kabeltyper Cat6, Cat6a
Maksimal overførselsafstand 70 m
Chipsæt GSV5100
Maksimal opdateringshastighed 60 Hz
Lyd-output kanaler 2.0 kanaler
LED-indikatorer Ja
Stativ-montering Ingen
Daisy kæde Ingen
Produktfarve Sort
Understøttede Windows-operativsystemer Ja
Understøttede Mac-operativsystemer Ja
Forbindelsesteknologi Ledningsført
RJ-45 indgangs-porte 4
RJ-45 udgangs-porte 4
HSMI-indgang 1
Antal HDMI-udgange 5
Fjernbetjening (IR) indgang 4
Fjernbetjening (IR) udgang 1
DC-in-stik Ja
Vekselstrømsindgangsspænding 100 - 240 V
Driftsspænding 12 V
Indgangsstrøm 0.8 A
Udgangsstrøm 2 A
Strømforbrug (typisk) 24 W
Strømstiktype Type M
Driftstemperatur (T-T) 0 - 50 °C
Opbevaringstemperatur (T-T) -10 - 70 °C
Relativ luftfugtighed ved drift (H-H) 5 - 90%
Bredde 103 mm
Dybde 180 mm
Højde 23 mm
Vægt 375 g
Pakkebredde 423 mm
Pakkedybde 345 mm
Pakkehøjde 60 mm
Pakkevægt 1,2 kg
AC-adapter inkluderet Ja
Inkluderede strømstik typer ANZ, EU, NA, UK
Hurtig start guide Ja
IR blaster inkluderet Ja
IR-modtager inkluderet Ja
Monteringssæt Ja
Emballageindhold 1 - HDMI Transmitter 4 - HDMI Receiver
Compliance-certifikater Federal Communications Commission (FCC), RoHS
Hovedkassens bredde (udvendigt) 450 mm
Hovedkassens længde (udvendigt) 367 mm
Hovedkassen højde (udvendigt) 525 mm
Produkter pr. hovedkasse (udvendigt) 6 stk
