Shuttle XPС slim DH610V2 PC barebone 1,35 L størrelse PC Sort Intel H610 LGA 1700

SKU: 1004040156
EAN: 0887993008950

Shuttle XPС slim DH610V2, 1,35 L størrelse PC, Mini PC barebone, Intel H610, LGA 1700, DDR5-SDRAM, 120 W
Mere info
2.479,00 DKK Ex. moms: 1.983,20 DKK På lager

Produktbeskrivelse

The Shuttle XPC slim Barebone DH610V2 with H610 chipset houses the performance of Intel's 12th/13th/14th generation Core desktop processors (codenamed Alder Lake-S and Raptor Lake-S [Refresh]) for socket LGA1700 in a compact 1.3-litre format. The DH610V2 allows for three Ultra HD displays to be operated at the same time via 1x HDMI and 2x DisplayPort. It also offers Dual Intel LAN (one supports 2.5G speed), eight USB ports and two COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.

Specifikationer

Produktfarve Sort
Pakkevægt 2,1 kg
Bredde 165 mm
Højde 43 mm
Vægt 1,3 kg
Dybde 190 mm
Relativ luftfugtighed ved drift (H-H) 10 - 90%
Understøttede Windows-operativsystemer Windows 10, Windows 11
Understøttede Linux-operativsystemer Ja
Driftstemperatur (T-T) 0 - 50 °C
Vekselstrømsindgangsspænding 100 - 240 V
Vekselstrømsindgangsfrekvens 50/60 Hz
Ethernet LAN-porte (RJ-45) 2
Ethernet LAN Ja
LAN Kontroller Intel I226, Intel I219V
Hurtig start guide Ja
Produkttype Mini PC barebone
LED-indikatorer Strøm, HDD
Antal USB 2.0-porte 4
Udgange til hovedtelefoner 1
Bæredygtighedscertifikater ENERGY STAR, ErP
Indbyggede højttaler(e) Ingen
Processor sokkel LGA 1700
Wi-Fi Ingen
VESA montering Ja
Slot til kabellås Ja
Panel montering grænseflade 75 x 75,100 x 100 mm
Kabellåseslids type Kensington
Hukommelseskanaler To-kanals
Fejlkorrigerende kode Ingen
On-board grafikkort Ja
Understøttede hukommelsestyper DDR5-SDRAM
Maksimal intern hukommelse 96 GB
Husmateriale Metal
Strømforsyningstype Ekstern AC-adapter
Indbygget processer Ingen
Tænd-/slukkontakt Ja
AC-adapter inkluderet Ja
DisplayPort-version 1.4
DC-in-stik Ja
Antal HDMI-porte 1
Antal DisplayPorts 2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte 3
Udgangsspænding for vekselstrømsadapter 19 V
Vekselstrømsadapterens udgangsstrøm 6,32 A
Understøttede lagerdisk størrelser 2.5,M.2
Kølingstype Aktiv
Drivere inkluderet Ja
Mikrofonindgang Ja
NVMe Ja
Antal serielle porte 2
HDMI-version 2.0b
Antal strømforsyninger 1
Strømledning inkluderet Ja
Strømforsyning 120 W
Hukommelsesspænding 1.1 V
Kabinettype 1,35 L størrelse PC
Datalagringsdriver installeret Ingen
Understøttet datalagringsdrev typer HDD & SSD
Bundkort chipsæt Intel H610
Trusted Platform Module (TPM) Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte 1
Trusted Platform Module (TPM) version 2.0
Antal hukommelsesstik 2
Hukommelses slots type SO-DIMM
Ikke-fejlkorrigerende kode Ja
Understøttede hukommelsesclock-hastigheder 5600 MHz
BIOS-type AMI
Antal understøttede processorer 1
Lydchip Realtek ALC888S
Compliance-certifikater BSMI, CE, Federal Communications Commission (FCC), RCM, VCCI, ETL, CB, RoHS
Installeret intern hukommelse Ingen
