StarTech.com ST10GSPEXNDP2 netværkskort Intern Ethernet 10000 Mbit/s

SKU: 1000841322
EAN: 0065030897693

StarTech.com ST10GSPEXNDP2, Intern, Ledningsført, PCI Express, Ethernet, 10000 Mbit/s, Sort
Mere info
3.309,00 DKK Ex. moms: 2.647,20 DKK På lager

Produktbeskrivelse

AVB | PXE Boot | PCIe 3.0 x4 | Marvell AQC113CSInstall this 2-port 10GbE PCI Express (PCIe) Network Interface Card (NIC) into a server or computer to enable fast network speeds and enhanced network functionality by providing failover and redundancy protection to mission-critical servers/applications.This Card supports six speeds: 10/5/2.5/1Gbps and 100/10Mbps with auto-negotiation for instant compatibility with new and legacy hardware. In addition, 10GBASE-T and NBASE-T (2.5GBASE-T/5GBASE-T) capabilities ensure compatibility with the latest network switches and access points manufactured by Cisco®; HPE®; and Aruba Networks®.10GbE Network SpeedsThis PCIe Network Card enables access to two high-bandwidth ethernet connections. As a result, it reduces network degradation when running data-intensive applications/processes such as FTPs, online storage/backup, and streaming online content. The Ethernet Network Card supports 10GBASE-T using existing Cat6 (or better) cable infrastructure.Enhance Existing HardwareNBASE-T technology maximizes the capability of Cat5e copper infrastructure over distances of up to 100 meters. The Network Interface Card connects to a PCIe x4 3.0/4.0 (or higher) slot and comes with a full-height bracket preinstalled, and a low-profile bracket is included. This Card is compatible with Windows, Windows Server, and Linux operating systems.Take advantage of advanced features such as load balancing in server or network equipment, bridging two different networks on one system, Audio Video Bridging (AVB), VLAN tagging (802.1Q), 16K-byte Jumbo Frames, full-duplex (FDX), UEFI Secure Boot (SB), and Preboot eXecution Environment (PXE).The PCIe 10GbE NIC is backed for 2 years, including free lifetime 24/5 multi-lingual technical assistance.The StarTech.com Advantage

Specifikationer

Produktfarve Sort
Pakkevægt 208 g
Bredde 20 mm
Højde 65 mm
Vægt 116 g
Dybde 145 mm
Relativ luftfugtighed ved drift (H-H) 20 - 80%
Opbevaringstemperatur (T-T) -10 - 60 °C
Pakkebredde 145 mm
Pakkedybde 215 mm
Pakkehøjde 35 mm
Grænseflade Ethernet
Understøttede Windows-operativsystemer Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Understøttede Linux-operativsystemer Ja
Driftstemperatur (T-T) 5 - 50 °C
Intern Ja
Netværksstandarder IEEE 802.3, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u
Fuld duplex Ja
Ethernet LAN-datahastigheder 10,100,1000,2500,5000,10000 Mbit/s
Maksimal dataoverførselshastighed 10000 Mbit/s
Forbindelsesteknologi Ledningsført
Værtsgrænseflade PCI Express
Ethernet LAN-porte (RJ-45) 2
PCI version 3.0
PCI-kort formfaktor Fuld højde (lav profil)
Ethernet LAN Ja
Maksimal driftstilstand 100 m
Hovedkassens bredde (udvendigt) 440 mm
Hovedkassens længde (udvendigt) 370 mm
Hovedkassen højde (udvendigt) 315 mm
Produkter pr. hovedkasse (udvendigt) 40 stk
LED-indikatorer Aktivitet, Link, Status
Jumbo Frames support Ja
Jumbo rammer 16000
Bæredygtighedscertifikater CE
Komponent til PC/server
Hurtig installationsvejledning Ja
Ethernet-grænsefladetype 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Hurtigt ethernet, Gigabit Ethernet
Kabelteknologi 10GBase-T
Wake-on-LAN klar Ja
Chipsæt Marvell AQC113CS
Understøttede operativsystemer til servere Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Auto MDIX IEEE Ja
VLAN mærkning Ja
Overholdelse af bæredygtighed Ja
Monteringsbeslag inkluderet Ja
