APC EPDU1232B strømforsyningsenhed (PDU) 42 AC stikkontakt(er) 0U Sort

SKU: 995772268
EAN: 0731304405061

APC EPDU1232B, Basis, 0U, Trefaset, Lodret, Sort, 42 AC stikkontakt(er)
Mere info
10.099,00 DKK Ex. moms: 8.079,20 DKK På lager

Produktbeskrivelse

APC Easy Basic Rack PDU EPDU1232B is Easy-to-install and easy-to-use PDU, making rack power distribution easy. This offers more than a power strip for server rack and network rack solutions. This is Vertical rack mountable PDU in ultra light weight upto 50% weight reduction with Aluminum housing. This is integrated with Hydraulic-magnetic circuit breakers (in units with 32A input current). EPDU1216B has IEC 309 32A 3P+N+E type inlet, Thirty IEC C13 and twelve IEC C19 type outlet sockets. This can operate from -5° to +45°C temperation range and comes with 1 year of standard warranty. Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. The packaging includes installation guide, toolless mounting kit and mounting brackets for quick and easy mounting in the rear of the enclosure. Saves time and money during installation by using one branch whip and standard connections. Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements.

Specifikationer

Type Trefaset
Produktfarve Sort
Pakkevægt 6,2 kg
Bredde 62 mm
Højde 1794 mm
Vægt 5,14 kg
Dybde 44 mm
Relativ luftfugtighed ved drift (H-H) 5 - 95%
Opbevaringstemperatur (T-T) -25 - 65 °C
Pakkebredde 160 mm
Pakkedybde 110 mm
Pakkehøjde 1950 mm
Certificering CE, TUV
Driftstemperatur (T-T) -5 - 45 °C
Vekselstrømsindgangsfrekvens 50 - 60 Hz
Relativ luftfugtighed ved opbevaring (H-H) 5 - 95%
Strømstik IEC 60309
Brugervejledning Ja
Strøm (maks.) 32 A
Montering Lodret
Kabellængde 2 m
Driftshøjde 0 - 3000 m
Ikke-drift højde 0 - 15000 m
Rackkapacitet 0U
AC stikkontakt typer C13 forbinder, C19 forbinder
AC udgange, antal 42 AC stikkontakt(er)
Nominel udgangsspænding 230 V
Nominel indgangsspænding 400 V
Maksimal ydeevne 22000 W
PDU-typer Basis
Load-kapacitet 22080 VA
Maksimal input strøm pr. fase 32 A
Samlet CO2-fodaftryk (kg of CO2e) 127,67
