XPG PYLON 650W enhed til strømforsyning 24-pin ATX ATX Sort

SKU: 998005939
EAN: 4710273776873

XPG PYLON 650W, 650 W, 100 - 240 V, 50 - 60 Hz, 10/5 A, Aktiv, 110 W
Mere info
529,00 DKK Ex. moms: 423,20 DKK På lager

Produktbeskrivelse

XPG PYLON offers more than just a Bronze-certified Power Supply. Highly efficient DC-to-DC converters and continuous power in 4 different wattage options are making it an ideal PSU pick for all usages.

DC-to-DC Circuit in BRONZE Grade

XPG PYLON complies with Intel ATX Power Supply Design Guide‘s sleep mode function, featuring DC-to-DC 100% +12V Full Power in all PYLON series, ensuring that power delivery remains consistent, power-efficient, and capable of supporting mid to high-end graphic cards and CPUs.

80 Plus Bronze Certification

XPG PYLON is a 80 Plus Bronze certified power supply unit that guarantees energy efficiency at 20%, 50% and 100% of rated loads. XPG PYLON also complies with ErP 2014 Lot 3 Regulation, and it is designed for steady 24/7 Continuous Power system operation.

Cybenetics ETA and LAMBDA Certified

XPG PYLON SERIES is certified by Cybenetics for its efficiency and noise level, scoring at the top of its category in both ETA and LAMBDA standards.

120mm Fluid Dynamic Bearing (FDB) Fan

The fan control of the built-in 120mm Fluid Dynamic Bearing (FDB) Fan starts at around 700 rpm (25°C ambient) and maintains its low fan speed until around 70% power load.
The operating environment is kept quiet and efficient, and prolongs its life expectancy.

Main Japanese Capacitor at 105°C

High quality 105°C Main Japanese Capacity in XPG PYLON Bronze Series ensures great durability and offer highest stability and reliability.

8 Industrial-Level Protections

XPG PYLON is designed for both efficiency and safety, and backed up by a 3-Year warranty. Fundamental protections such as OPP, UVP, OVP, SCP, OTP and OCP are all included, as well as NLO and SIP which are found in mid to high-end PSU, offering one of the highest standards of stability and security in this category.

Specifikationer

Harmoniseret systemkode (HS) 84733020
Produktfarve Sort
Bredde 140 mm
Højde 86 mm
Dybde 150 mm
Certificering CE / CB(62368+60950) / FCC(IC) / EAC / CCC / TUV / cTUVus / TUV-S / RCM / NOM / BSMI / KC
Gennemsnitstid mellem fejl (MTBF) 100000 t
Vekselstrømsindgangsspænding 100 - 240 V
Vekselstrømsindgangsfrekvens 50 - 60 Hz
Kabeltype Ikke modulær
Formål PC
Indgangsstrøm 10/5 A
Bæredygtighedscertifikater ErP
Kabler inkluderet Vekselstrøm
Strømbeskyttelsesfunktioner Overstrøm, Overstrøm, Højspænding, Overophedning, Kortslutning, Lavspænding
Ventilator diameter 12 cm
Antal blæsere 1 blæser(e)
Lejeteknologi FDB
Total effekt 650 W
Kølingstype Aktiv
Strøm faktor 0,99
Overholdelse af bæredygtighed Ja
Maks. udgangsstrøm (+12 V) 54 A
80 PLUS certificering 80 PLUS Bronze
Kombineret effekt (+3,3 V) 110 W
Kombineret effekt (+12 V) 648 W
Kombineret effekt (+5 V) 110 W
Maks. udgangsstrøm (+3,3 V) 20 A
Maks. udgangsstrøm (+5 V) 20 A
Maks. udgangsstrøm (-12V) 0,3 A
Maks. udgangsstrøm (+5 VSB) 2,5 A
Motherboard, strømstik 24-pin ATX
Perifere (Molex) strømstik (4-pin) 1
Antal SATA strømstik 8
ATX strømstrik (24 stikben) Ja
Strømforsyningenhed (PSU) formfaktor ATX
Strømkorrektionsfaktor (PFC) Aktiv
Kombineret effekt (-12V) 3,6 W
Kombineret effekt (+5 VSB) 12,5 W
PCI ekspres strømforbindelser (6+2 pin) 4
ATX-version 2.4
EPS-strømstik (4 + 4-benet) Ja
Compliance-certifikater RoHS
