D-Link DGS-1100-16V2 Administreret L2 Gigabit Ethernet (10/100/1000) Sort

SKU: 1000623847
EAN: 0790069467820

D-Link DGS-1100-16V2, Administreret, L2, Gigabit Ethernet (10/100/1000), Fuld duplex, Stativ-montering
Mere info
1.089,00 DKK Ex. moms: 871,20 DKK På lager

Produktbeskrivelse

Powerful Switching for your Business
The DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.

Gigabit Ethernet Speeds
Take your Ethernet speeds to the next level with Gigabit Connectivity

Cutting Edge Green Technology
Innovative D-Link Green power saving features keep your budget in check

Manage Anywhere, Anytime
Remote setup & management is easy, and can be done from anywhere.

Easy to Use & Easy to Install
D-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.

VLANs: Stronger Security & Better Traffic Management
Relatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.

For Voice
If VoIP calls make up a large slice of your network usage, separating them onto their own VLAN can ensure they get the bandwidth they need for smooth conversations without lag or jitters.

For Surveillance
If you have surveillance cameras and devices attached to your network, putting them onto their own VLAN keeps surveillance footage running seamlessly. At the same time, it can help prevent a variety of malicious attacks by restricting access to different network areas.

Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.

Specifikationer

Switch-type Administreret
Switch lag L2
Servicekvalitet support (QoS) Ja
Webbaseret administration Ja
System hændelseslog Ja
Basis omskiftning RJ-45 Ethernet porte, antal 16
Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000)
Antal installerede SFP moduler 0
Antal installerede SFP+ moduler 0
Netværksstandarder IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G understøttelse Ingen
Kobber ethernet kabelteknologi 10BASE-T, 10BASE-TX, 1000BASE-T
Port-spejlning Ja
Fuld duplex Ja
Flowkontrol support Ja
Link aggregering Ja
Broadcast stormkontrol Ja
Begrænsning af hastighed Ja
Auto MDI/MDI-X Ja
Spanning tree protokol Ja
Head-of-line (HOL) blokering Ja
Ethernet LAN-datahastigheder 10,100,1000 Mbit/s
Auto-forhandling Ja
VLAN understøttelse Ja
Vituelle LAN funktioner Port-based VLAN, Voice VLAN
Antal VLAN'er 128
MAC adresselabel 8000 entries
Switch kapacitet 32 Gbit/sek.
Hastighed for videresendelse 23,81 Mpps
Opbevar-og-frem Ja
Antal køer 4
Jumbo Frames support Ja
Jumbo rammer 9216
Pakke bufferlager 4,1 MB
DHCP funktioner DHCP client
IGMP snooping Ja
Sikkerhedsalgoritmer SNMP, SSL/TLS
Algoritmer for køplanlægning SPQ, Weighted Round Robin (WRR)
Multicast-understøttelse Ja
Stativ-montering Ja
Produktfarve Sort
LED-indikatorer Ja
Indbygget processer Ja
Processorfrekvens 125 MHz
Hukommelsestype DRAM
Flashhukommelse 16 MB
Støjniveau 0 dB
Ventilatorfri Ja
Gennemsnitstid mellem fejl (MTBF) 710519 t
Strømkilde Vekselstrøm
Vekselstrømsindgangsspænding 100 - 240 V
Vekselstrømsindgangsfrekvens 50/60 Hz
Strømforbrug (maks.) 10,1 W
Strøm over Ethernet (PoE) Ingen
Driftstemperatur (T-T) -5 - 50 °C
Opbevaringstemperatur (T-T) -40 - 70 °C
Relativ luftfugtighed ved drift (H-H) 0 - 95%
Relativ luftfugtighed ved opbevaring (H-H) 0 - 95%
Driftshøjde 0 - 2000 m
Varmeafgivelse 34,46 BUT/t
Bredde 280 mm
Dybde 180 mm
Højde 44 mm
Vægt 1,27 kg
Certificering EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC
