D-Link DGS-1510-28XMP Administreret L2/L3 Gigabit Ethernet (10/100/1000) Strøm over Ethernet (PoE) Sort, Grå

SKU: 1000623872
EAN: 0790069467943

D-Link DGS-1510-28XMP, Administreret, L2/L3, Gigabit Ethernet (10/100/1000), Fuld duplex, Strøm over Ethernet (PoE), Stativ-montering
Mere info
9.549,00 DKK Ex. moms: 7.639,20 DKK På lager

Produktbeskrivelse

Industry Standard CLI with 10G SFP+ stacking
The D-Link DGS-1510 Series is the latest generation of Smart Managed switches with 10G SFP+ fibre ports for physical stacking or uplinks. The combination of high bandwidth connections, an Industry Standard CLI, and PoE options make the DGS-1510 Series ideal for Small-Medium Enterprise environments.

Fully‑Featured with Layer 3 Traffic Management
The DGS-1510 family has advanced network management options, accessible via Industry Standard CLI, Serial Port Console or the Web-based UI, that equip your business with network capabilities such as VLANs, multiple spanning tree protocol (MSTP), link aggregation (LACP), static routing, multiple firmware images,and multiple configuration files.

10G SFP+ Stacking
Create a physical stack of up to 6 units in a fault‑tolerant ring or linear topology using Direct Attach Cables or any compatible SFP+ transceivers for a total of 288 Gigabit ports. The remaining uplink ports can be used for other functions, offering 10G connectivity to core networks and servers.1

With powerful security features like IGMP snooping, access control lists, port security, and the unique D-Link Safeguard Engine that protects your network against malicious denial-of-service attacks from broadcast, multicast and unicast flooding, the DGS-1510 family is a versatile solution for enterprise network environments.

Max PoE with budgets up to 740W2
Choose between 193W and 370W power budget options. Or utilise a total of 740W when adding a redundant power supply to the DGS-1510-52XMP.

Powerful Network Design and Management Software
The DGS-1510 Series supports D-View 8, an intelligent management platform that allows for centralized management of the core network. This extensive toolset enables administrators to easily set up and remotely manage their networks, greatly reducing switch deployment time.

Smart Energy‑Saving Design
D-Link Green technology enables the DGS-1510 series to save power without sacrificing performance. The entire series of switches feature a smart fan that adjusts fan-speed and only powers on above a certain temperature. With advanced silicon technology, the DGS-1510 series saves up to 73% of energy compared to normal switches.

Specifikationer

Harmoniseret systemkode (HS) 85176990
Produktfarve Sort, Grå
Pakkevægt 7,06 kg
Bredde 440 mm
Højde 44 mm
Vægt 4,25 kg
Dybde 308,5 mm
Relativ luftfugtighed ved drift (H-H) 0 - 95%
Opbevaringstemperatur (T-T) -20 - 70 °C
Pakkebredde 450 mm
Pakkedybde 510 mm
Pakkehøjde 121 mm
Driftstemperatur (T-T) -5 - 50 °C
Pallens bruttobredde 120 cm
Pallens bruttolængde 110 cm
Switch-type Administreret
Servicekvalitet support (QoS) Ja
Basis omskiftning RJ-45 Ethernet porte, antal 24
Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000)
Netværksstandarder IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
10G understøttelse Ja
Fuld duplex Ja
Flowkontrol support Ja
MAC adresselabel 16384 entries
Switch kapacitet 128 Gbit/sek.
Stativ-montering Ja
Stabelbar Ja
Gennemsnitstid mellem fejl (MTBF) 274796 t
Strømkilde Vekselstrøm
Vekselstrømsindgangsspænding 100 - 240 V
Strøm over Ethernet (PoE) Ja
Relativ luftfugtighed ved opbevaring (H-H) 0 - 95%
LED-indikatorer Aktivitet, Link, PoE, Strøm, Hastighed
Kobber ethernet kabelteknologi 10BASE-T, 100BASE-TX, 1000BASE-T
Auto MDI/MDI-X Ja
Auto-forhandling Ja
MAC-adresse auto-indlæring understøttet Ja
Opbevar-og-frem Ja
Strømforsyning inkluderet Ja
Strømforbrug (maks.) 436,3 W
Varmeafgivelse 1487,78 BUT/t
Jumbo Frames support Ja
Jumbo rammer 9216
Pakke bufferlager 1,5 MB
Fiber optisk strømstik SFP+
Sikkerhed cUL, CB
Indbygget processer Ja
Flashhukommelse 32 MB
Pallehøjde (luft) 2,08 m
Understøttede kabeltyper Cat5, Cat5e
Power over Ethernet (PoE) porte, antal 24
Power over Ethernet (PoE) effekt pr. port 30 W
Total Power over Ethernet (PoE) 370 W
VLAN understøttelse Ja
Sikkerhedsalgoritmer 802.1x RADIUS, EAP, SNMP, SSH, SSH-2, SSL/TLS
System hændelseslog Ja
Intern hukommelse 256 MB
Palle bruttovægt (luft) 561,6 kg
Antal papkasser pr. palle (luft) 24 stk
Antal pr. palle (luft) 72 stk
Palle bruttovægt (hav) 561,6 kg
Antal papkasser pr. palle (hav) 24 stk
Antal pr. palle (hav) 72 stk
Pallehøjde (hav) 2,08 m
Forsendelseskasses kassens bredde (indvendig) 38,5 cm
Forsendelseskassens længde (indvendig) 53 cm
Forsendelseskassens højde (indvendig) 48,5 cm
Forsendelseskassens bruttovægt (indvendig) 22,6 kg
Produkter pr. forsendelseskasse (indvendig) 3 stk
Forsendelsesemballage nettovægt 14,3 kg
Antal blæsere 2 blæser(e)
Switch lag L2/L3
Port-spejlning Ja
Link aggregering Ja
Broadcast stormkontrol Ja
Spanning tree protokol Ja
DHCP funktioner DHCP server, DHCP client
Adgangskontrolliste (ACL) Ja
IGMP snooping Ja
SSH/SSL support Ja
BPDU filtrering/beskyttelse Ja
Godkendelse MAC-baseret godkendelse, Portbaseret godkendelse
Multicast-understøttelse Ja
Processorfrekvens 400 MHz
Gennnemløb 95,24 Mpps
Vituelle LAN funktioner Tagged VLAN, Protocol-based VLAN
Antal VLAN'er 4094
Antal køer 8
Head-of-line (HOL) blokering Ja
Antal SFP + modulslots 4
Adgangskontrolliste (ACL) regler 768
Trafik klassificering Ja
Antal installerede SFP+ moduler 0
Antal installerede SFP moduler 0
