NETGEAR M4250-10G2XF-PoE+ Administreret L2/L3 Gigabit Ethernet (10/100/1000) Strøm over Ethernet (PoE) 1U Sort

SKU: 996482331
EAN: 0606449149586

NETGEAR M4250-10G2XF-PoE+, Administreret, L2/L3, Gigabit Ethernet (10/100/1000), Strøm over Ethernet (PoE), Stativ-montering, 1U
Mere info
10.939,00 DKK Ex. moms: 8.751,20 DKK På lager

Produktbeskrivelse

Switching engineered for 1G AV over IP with PoE+, Ultra90 PoE++ and rear-facing ports ensuring a clean integration in AV racks. M4250 switches come pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately. For video the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Dante etc. as well as audio/video/control mixed profiles. When multiple switches, NETGEAR IGMP Plus brings automation for you to just connect them together.

M4250 Support for Audio Video Bridging (AVB)
One of the many features designed into the new M4250 product line is full support for Audio Video Bridging (AVB), an industry standard for transporting content over a network. AVB is used most often when very low latency is required such as in live performances when lip sync is critical. All of the AV Line M4250 switches can be optionally licensed for AVB support.

Specifikationer

Harmoniseret systemkode (HS) 85176990
Produktfarve Sort
Bredde 440 mm
Højde 43,2 mm
Vægt 2,96 kg
Dybde 200 mm
Relativ luftfugtighed ved drift (H-H) 0 - 90%
Opbevaringstemperatur (T-T) -20 - 70 °C
Driftstemperatur (T-T) 0 - 50 °C
Switch-type Administreret
Servicekvalitet support (QoS) Ja
Basis omskiftning RJ-45 Ethernet porte, antal 10
Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000)
Netværksstandarder IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x
10G understøttelse Ingen
Fuld duplex Ja
MAC adresselabel 16000 entries
Switch kapacitet 60 Gbit/sek.
Stativ-montering Ja
Støjniveau 39,22 dB
Gennemsnitstid mellem fejl (MTBF) 947871 t
Strømforbrug (typisk) 306,4 W
Strøm over Ethernet (PoE) Ja
Relativ luftfugtighed ved opbevaring (H-H) 0 - 95%
Formfaktor 1U
LED-indikatorer PoE, Strøm, Status
Opbevar-og-frem Ja
Varmeafgivelse 1046,05 BUT/t
Jumbo Frames support Ja
Jumbo rammer 12000
Pakke bufferlager 16 MB
Processormodel ARM Cortex-A9
Driftshøjde 0 - 3000 m
Ikke-drift højde 0 - 3000 m
Indbygget processer Ja
Power over Ethernet (PoE) effekt pr. port 30 W
Total Power over Ethernet (PoE) 240 W
VLAN understøttelse Ja
Intern hukommelse 2048 MB
Switch lag L2/L3
Link aggregering Ja
Broadcast stormkontrol Ja
Begrænsning af hastighed Ja
Spanning tree protokol Ja
DHCP funktioner DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
Adgangskontrolliste (ACL) Ja
IGMP snooping Ja
SSH/SSL support Ja
BPDU filtrering/beskyttelse Ja
Godkendelse MAC-baseret godkendelse
Multicast-understøttelse Ja
Processorfrekvens 1250 MHz
Gennnemløb 44,64 Mpps
Vituelle LAN funktioner MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Antal VLAN'er 4093
Antal køer 8
Godkendelsestype RADIUS
Power over Ethernet plus (PoE+) porte, antal 8
Antal SFP + modulslots 2
Loop beskyttelse Ja
Latens (1 Gbps) 2,14 µs
IPv4 multicast indtastninger 2000
IPv6 multicast indtastninger 2000
Antal installerede SFP+ moduler 0
Antal installerede SFP moduler 0
