StarTech.com PEXUSB3S44V interface-kort/adapter Intern USB 3.2 Gen 1 (3.1 Gen 1)

SKU: 988493458
EAN: 0065030854627

StarTech.com PEXUSB3S44V, PCIe, USB 3.2 Gen 1 (3.1 Gen 1), Fuld højde/ lav profil, PCIe 2.0, Sort, 3 m
Mere info
919,00 DKK Ex. moms: 735,20 DKK På lager

Produktbeskrivelse

Add four USB 3.0 (USB 3.2 Gen 1) ports with four independent channels, LP/SATA power, and charging support to your PC through a PCI Express slot

The PEXUSB3S44V 4-Port PCI Express USB 3.2 Gen 1 Card lets you add four, dedicated 5 Gbps USB 3.2 Gen 1 ports to your PCIe x4-enabled PC. This independent port architecture improves USB 3.2 Gen 1 performance by transferring data on four individual channels to your computer, giving you faster file transfers.

When multiple devices are connected, traditional single bus USB 3.2 Gen 1 cards share your maximum bandwidth between all ports. By employing four host controller chipsets, each port operates on a separate independent transmission channel. Dedicating up to 5 Gbps to each USB port reduces performance bottlenecks, and effectively quadruples your total available to bandwidth to 20 Gbps.

Enhanced with UASP support (USB Attached SCSI Protocol), this USB 3.2 Gen 1 controller performs up to 70% faster than conventional USB 3.2 Gen 1 when paired with a UASP supported enclosure (Note: UASP requires a compatible operating system). Using a more efficient protocol than the traditional USB BOT (Bulk-Only Transport), UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly increasing transfer speeds for less wait time on data transfers. See our UASP test results below for further details.

For high-power USB devices, this PCIe USB 3.2 Gen 1 card includes an optional SATA or LP4 power connector to connect to your system power supply and deliver up to 900mA of power per port to USB 3.2 Gen 1 bus-powered devices (500mA for USB 2.0). The USB 3.2 Gen 1 card also supports USB Battery Charging Specification 1.2 (Apple Mode only), letting you charge compatible Apple devices (iPhones and iPads) faster than a standard USB 3.2 Gen 1 port.

The controller card is compliant with USB 3.2 Gen 1 standards while offering backward compatibility with existing USB 2.0 / 1.1 devices. For added versatility, the USB 3.2 Gen 1 PCIe card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Improved Performance with UASP

UASP is supported in Windows® 8, 8.1, Server 2012 and Linux kernel 2.6.37 or later. In testing UASP performed with up to a 70% faster read / 40% faster write speed over traditional USB 3.2 Gen 1 at peak performance.

At the same peak in testing, UASP also showed up to an 80% reduction in required processor resources.

Test results were obtained using an Intel® Ivy Bridge system, StarTech.com add-on USB 3.2 Gen 1 cards, a UASP-enabled StarTech.com enclosure, and a SATA III solid state drive.

The StarTech.com Advantage

Specifikationer

Harmoniseret systemkode (HS) 84733020
Produktfarve Sort
Pakkevægt 202 g
Bredde 15 mm
Højde 120 mm
Vægt 92 g
Dybde 167 mm
Relativ luftfugtighed ved drift (H-H) 5 - 85%
Opbevaringstemperatur (T-T) -20 - 60 °C
Pakkebredde 145 mm
Pakkedybde 208 mm
Pakkehøjde 41 mm
Understøttede Windows-operativsystemer Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64
Understøttede Linux-operativsystemer Ja
Driftstemperatur (T-T) 0 - 50 °C
Intern Ja
Værtsgrænseflade PCIe
Hovedkassens bredde (udvendigt) 418 mm
Hovedkassens længde (udvendigt) 441 mm
Hovedkassen højde (udvendigt) 313 mm
Produkter pr. hovedkasse (udvendigt) 40 stk
Brugervejledning Ja
Brugervejledning Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte 4
Output-grænseflade USB 3.2 Gen 1 (3.1 Gen 1)
Chipsæt Renesas/NEC - µPD720202
Understøttede operativsystemer til servere Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Drivere inkluderet Ja
Udvidelseskort formfaktor Fuld højde/ lav profil
Udvidelseskort standard PCIe 2.0
Maksimal kabellængde 3 m
Dataoverførselshastighed (maks.) 20 Gbit/sek.
Understøtter UASP Ja
Perifere (Molex) strømstik (4-pin) 1
Compliance-certifikater RoHS
